TYPICAL GC20665-L14-D industrial lockstitch machine with compound feed for heavy sewing


GC20665-L14-D/KPL

TYPICAL

New product


This model is an improved version of TYPICAL lockstitches from a series of sewing machines for furniture and car upholstery and other thick materials. GC20665-L14-D is a...

More details

Ask for price

(+48) 42 212-14-50

Add to wishlist

This model is an improved version of TYPICAL lockstitches from a series of sewing machines for furniture and car upholstery and other thick materials. GC20665-L14-D is a device that will also work in sewing bags, suitcases, sails and technical industrial fabrics. This is possible thanks to compound feed, a high needle bar stroke (36mm), the possibility of lifting the presser foot to a height of 16mm and a very solid machine head construction. This TYPICAL lockstitch is characterized by integrated with the head, very strong direct-drive. Sewing upholstery and other materials with a large area is much easier, because this industrial sewing machine is characterized by a bigger clearance under the arm (in this model it is up to 360mmx103mm). Among the advantages of this lockstitch it is also worth mentionig led light integrated with the machine head and about modern bobbin winder with a knife for cutting the thread. Everyday work with thick materials is also improved by enlarged hook (allowing the use of an enlarged bobbin, which when using thick threads is a very convenient solution) and new top feed with adjustment dial. Thanks to this function, the seams are always perfect, even in thickening places.

Technical parameters of TYPICAL GC20665-L14-D:

  • Compound feed
  • Direct-drive/Energy saving motor
  • Max. stitch length: 9mm
  • Maximum sewing speed: 2500 spm
  • Presser foot lift: 9/16mm
  • Enlarged hook
  • Needle bar stroke: 36mm
  • Built-in led light
  • Needle system: 135×17/DP×17
  • Max. thread thickness: 15/3
  • New bobbin winder with cutter
  • New top feed with adjustment dial

See how TYPICAL GC20665-L14-D works with heavy technical sewing:
